72 Electrical installation: input / output
When the MicroFlex e150 is connected to Mint WorkBench, the active level of the
outputs can be configured using the Digital I/O tool. Alternatively, the Mint keyword
OUTPUTACTIVELEVEL can be used. The state of the outputs is displayed in the Spy
window. See the Mint help file for details.
DOUT3 - typical connections to an ABB NextMove e100:
MicroFlex e150
DOUT3
CREF1
8
TLP280
9
2
10
DIN4
USRV+
OPT1 X9
TLP127
User
supply
24 V
User
supply
GND
NextMove e100 / controller
