Note: Technical drawings are delivered with the unit, only if you requested.
Auxiliary service transformer1
Surge arrester protection for the auxiliary service board2
Upstream on-load fuse switch for auxiliary service transformer protection3
Downstream circuit breaker for auxiliary service transformer protection4
Torch light and charger5
Auxiliary service board circuit breakers and differential protections6
Grounding busbar7
Terminals block8
Hardware description 21

ABB PVS-100 Series Specifications

General

Rated Power	100 kW
Max DC Voltage	1100 V
Number of MPPT	6
Protection Rating	IP65
Operating Temperature Range	-25°C to +60°C
Max AC Power	100 kW
Topology	Transformerless
Cooling	Forced air
AC Voltage Range	400 V
Frequency Range	50/60 Hz
