ABB PVS-100 Series User Manual

Tightening torque
Use the torque values given in the table, unless otherwise specified.
Electrical connections
Torque
Bolt and nuts
Brass (N.m)Steel: A2-70/A4-70/8.8 (N.m)
-0.9M3
-2.3M4
-4.5M5
5.08.0M6
1220M8
2540M10
4070M12
60110M14
90170M16
120240M18
Mechanical connection
1)
Torque
Bolt and nuts
A2-70/A4-70Quality 8.8
0.851.21M3
0.802.78M4
1.605.5M5
2.809.5M6
6.823M8
1446M10
2479M12
37127M14
56198M16
81283M18
114402M20
1)
Not applicable to threaded inserts
54 Maintenance

ABB PVS-100 Series Specifications

General

Rated Power	100 kW
Max DC Voltage	1100 V
Number of MPPT	6
Protection Rating	IP65
Operating Temperature Range	-25°C to +60°C
Max AC Power	100 kW
Topology	Transformerless
Cooling	Forced air
AC Voltage Range	400 V
Frequency Range	50/60 Hz
