Mechanical installation
Contents of this chapter
This chapter describes the mechanical installation of the PVS-100/120 medium voltage
compact skid (MVCS) and gives instructions on how to select the location and guidelines
to build the foundation for the MVCS. Always obey the local regulations.
Safety
See Safety instructions (page 9).
Before you move the MVCS, see instructions in chapter Storing, lifting and
transporting (page 29).
Tools
Use the following tools to move the MVCS, to fasten the MVCS foundation, and to tighten
the connections:
• Crane, forklift, or pallet truck (with sufficient load capacity)
• Pozidriv and Torx (2.5 to 6 mm) screwdrivers with short and long heads or bits
• Torque wrench
• Set of wrenches and sockets.
Foundation guidelines
For information on the MVCS dimensions and footprint, see drawing
3AES-PVS-100_120-MVCS-30-DW02.
Always follow the local rules and laws when designing and constructing the foundation. Pay
attention to the proper planning and constructing of the foundation. For example, an improper
foundation can cause settling of the MVCS or difficulty opening the door.
