ABB PVS-100 Series User Manual

Unloading
WARNING!
To prevent damage to the MVCS, keep the delivery packaging and protection
canvas on until you install it.
WARNING!
Inspect the MVCS carefully before performing any activity. Check that there is no
protuberance or any general poor condition.
Before unloading, follow these instructions:
1. Protect the corners of the MVCS against shock.
2. Make sure that the terrain is level and sturdy. Consider that the MVCS has an
approximate weight of 11 tons.
3. Unload the standard container carrying the MVCS inside. Follow local regulations and
applicable standards.
4. Remove all stops, and transportation slings at both ends and laterals.
￭ Tools used for unloading
• Five tons forklift
• Two guide platforms with length 5 m and width 500 mm
• Two belly chains of eight tons
• Two slings of eight tons. Minimum five meters.
34 Storing, lifting and transporting

ABB PVS-100 Series Specifications

General

Rated Power	100 kW
Max DC Voltage	1100 V
Number of MPPT	6
Protection Rating	IP65
Operating Temperature Range	-25°C to +60°C
Max AC Power	100 kW
Topology	Transformerless
Cooling	Forced air
AC Voltage Range	400 V
Frequency Range	50/60 Hz
