ABB PVS-100 Series User Manual

Maintenance
Contents of this chapter
This chapter contains the preventive maintenance instructions for the PVS-100/120 medium
voltage compact skid(MVCS). The instructions are intended for certified personnel to perform
maintenance tasks.
WARNING!
Only an authorized electrician is permitted to do maintenance work on the MVCS.
Obey the Safety instructions (page 9) and follow the local safety regulations. If
ignored, physical injury or death, or damage to the equipment may occur.
WARNING!
Do not do electrical work during a thunderstorm.
Tools list
• Torx drivers
• Philips screwdrivers (PoziDriv)
• Torque wrench
• Set of wrenches and sockets
• Cable and wire strippers
• Crimping tool and cable lugs
• Voltage detector
• Personal protective equipment
9
Maintenance 53

ABB PVS-100 Series Specifications

General

Rated Power	100 kW
Max DC Voltage	1100 V
Number of MPPT	6
Protection Rating	IP65
Operating Temperature Range	-25°C to +60°C
Max AC Power	100 kW
Topology	Transformerless
Cooling	Forced air
AC Voltage Range	400 V
Frequency Range	50/60 Hz
