Table 25: Description of the input-output relationship
VALID OPEN CLOSE
POSITION
Value Description
0 - - 0 Intermediate
1 0 0 0 Intermediate
1 1 0 1 Open
1 0 1 2 Closed
1 1 1 3 Bad State
12.6.3 Setting guidelines
SEMOD55398-5 v5
The function does not have any parameters available in the local HMI or PCM600.
12.7 Single point generic control 8 signals SPC8GAPC
SEMOD176448-1 v3
12.7.1 Identification
SEMOD176456-2 v3
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Single point generic control 8 signals SPC8GAPC - -
12.7.2 Application
SEMOD176511-4 v7
The Single point generic control 8 signals (SPC8GAPC) function block is a
collection of 8 single point commands that can be used for direct commands for
example reset of LED's or putting IED in "ChangeLock" state from remote. In this
way, simple commands can be sent directly to the IED outputs, without
confirmation. Confirmation (status) of the result of the commands is supposed to
be achieved by other means, such as binary inputs and SPGAPC function blocks.
PSTO is the universal operator place selector for all control
functions. Even if PSTO can be configured to allow LOCAL or
ALL operator positions, the only functional position usable with the
SPC8GAPC function block is REMOTE.
12.7.3 Setting guidelines
SEMOD176518-4 v7
The parameters for the single point generic control 8 signals (SPC8GAPC)
function are set via the local HMI or PCM600.
1MRK 505 393-UEN B Section 12
Control
Line differential protection RED650 2.2 IEC 271
Application manual
