Operation: turning the function operation On/Off.
There are two settings for every command output (totally 8):
PulseModex: decides if the command signal for output x is Latched (steady) or
Pulsed.
tPulsex: if PulseModex is set to Pulsed, then tPulsex will set the length of the pulse
(in seconds).
12.8 AutomationBits, command function for DNP3.0
AUTOBITS
SEMOD158589-1 v3
12.8.1 Identification
GUID-C3BB63F5-F0E7-4B00-AF0F-917ECF87B016 v4
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
AutomationBits, command function for
DNP3
AUTOBITS - -
12.8.2 Application
SEMOD158637-5 v4
Automation bits, command function for DNP3 (AUTOBITS) is used within
PCM600 in order to get into the configuration the commands coming through the
DNP3.0 protocol.The AUTOBITS function plays the same role as functions
GOOSEBINRCV (for IEC 61850) and MULTICMDRCV (for LON).AUTOBITS
function block have 32 individual outputs which each can be mapped as a Binary
Output point in DNP3. The output is operated by a "Object 12" in DNP3. This
object contains parameters for control-code, count, on-time and off-time. To
operate an AUTOBITS output point, send a control-code of latch-On, latch-Off,
pulse-On, pulse-Off, Trip or Close. The remaining parameters are regarded as
appropriate. For example, pulse-On, on-time=100, off-time=300, count=5 would
give 5 positive 100 ms pulses, 300 ms apart.
For description of the DNP3 protocol implementation, refer to the Communication
manual.
12.8.3 Setting guidelines
SEMOD158639-5 v3
AUTOBITS function block has one setting, (Operation: On/Off) enabling or
disabling the function. These names will be seen in the DNP3 communication
management tool in PCM600.
Section 12 1MRK 505 393-UEN B
Control
272 Line differential protection RED650 2.2 IEC
Application manual
