IEC 61850 or
function name
ANSI Function description Line differential
RED650 (A11)
I103IED IED status for IEC
60870-5-103
1
I103SUPERV Supervision status for IEC
60870-5-103
1
I103USRDEF Status for user defined signals
for IEC 60870-5-103
20
L4UFCNT Event counter with limit
supervision
30
TEILGAPC Running hour meter 6
Metering
PCFCNT Pulse-counter logic 16
ETPMMTR Function for energy
calculation and demand
handling
6
2.5 Communication
GUID-5F144B53-B9A7-4173-80CF-CD4C84579CB5 v16
IEC 61850 or
function name
ANSI Function description Line differential
RED650 (A11)
Station communication
LONSPA, SPA SPA communication protocol 1
ADE LON communciation protocol 1
HORZCOMM Network variables via LON 1
PROTOCOL Operation selection between SPA and IEC 60870-5-103 for SLM 1
RS485PROT Operation selection for RS485 1
RS485GEN RS485 1
DNPGEN DNP3.0 communication general protocol 1
CHSERRS485 DNP3.0 for EIA-485 communication protocol 1
CH1TCP, CH2TCP,
CH3TCP, CH4TCP
DNP3.0 for TCP/IP communication protocol 1
CHSEROPT DNP3.0 for TCP/IP and EIA-485 communication protocol 1
MSTSER DNP3.0 serial master 1
MST1TCP,
MST2TCP,
MST3TCP,
MST4TCP
DNP3.0 for TCP/IP communication protocol 1
DNPFREC DNP3.0 fault records for TCP/IP and EIA-485 communication protocol 1
IEC 61850-8-1 IEC 61850 1
Table continues on next page
1MRK 505 393-UEN B Section 2
Application
