IEC 61850 or
function name
ANSI Function description Line differential
RED650 (A11)
GOOSEINTLKRCV Horizontal communication via GOOSE for interlocking 59
GOOSEBINRCV GOOSE binary receive 16
GOOSEDPRCV GOOSE function block to receive a double point value 64
GOOSEINTRCV GOOSE function block to receive an integer value 32
GOOSEMVRCV GOOSE function block to receive a measurand value 60
GOOSESPRCV GOOSE function block to receive a single point value 64
GOOSEXLNRCV GOOSE function block to receive a switching device 3
MULTICMDRCV/
MULTICMDSND
Multiple command and transmit 60/10
OPTICAL103 IEC 60870-5-103 Optical serial communication 1
RS485103 IEC 60870-5-103 serial communication for RS485 1
AGSAL Generic security application component 1
LD0LLN0 IEC 61850 LD0 LLN0 1
SYSLLN0 IEC 61850 SYS LLN0 1
LPHD Physical device information 1
PCMACCS IED configuration protocol 1
SECALARM Component for mapping security events on protocols such as DNP3
and IEC103
1
FSTACCS Field service tool access 1
IEC 61850-9-2 Process bus communication, 4 merging units 1-P31
ACTIVLOG Activity logging 1
ALTRK Service tracking 1
PRP IEC 62439-3 Parallel redundancy protocol 1-P23
HSR IEC 62439-3 High-availability seamless redundancy 1-P24
PTP Precision time protocol 1
FRONTSTATUS Access point diagnostic for front Ethernet port 1
SCHLCCH Access point diagnostic for non-redundant Ethernet port 4
RCHLCCH Access point diagnostic for redundant Ethernet ports 2
DHCP DHCP configuration for front access point 1
QUALEXP IEC 61850 quality expander 32
Remote communication
BinSignRec1_1,
BinSignRec1_2,
BinSignReceive2,
BinSignTrans1_1,
BinSignTrans1_2,
BinSignTransm2
Binary signal transfer receive/transmit 3/3/6
LDCMTRN Transmission of analog data from LDCM 1
LDCMRecBinStat1,
LDCMRecBinStat2,
LDCMRecBinStat3
Receive binary status from remote LDCM 6/3/3
Scheme communication
Table continues on next page
Section 2 1MRK 505 393-UEN B
Application
34 Line differential protection RED650 2.2 IEC
Application manual
