14.9 Boolean to integer conversion with logical node
representation, 16 bit BTIGAPC
SEMOD175753-1 v4
14.9.1 Identification
SEMOD175757-2 v5
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Boolean to integer conversion with
logical node representation, 16 bit
BTIGAPC - -
14.9.2 Application
SEMOD175849-4 v6
Boolean to integer conversion with logical node representation, 16 bit (BTIGAPC)
is used to transform a set of 16 binary (logical) signals into an integer. BTIGAPC
has a logical node mapping in IEC 61850.
The BTIGAPC function will transfer a combination of up to 16 binary inputs INx
where 1≤x≤16 to an integer. Each INx represents a value according to the table
below from 0 to 32768. This follows the general formula: INx = 2
x-1
where
1≤x≤16. The sum of all the values on the activated INx will be available on the
output OUT as a sum of the values of all the inputs INx that are activated. OUT is
an integer. When all INx where 1≤x≤16 are activated that is = Boolean 1 it
corresponds to that integer 65535 is available on the output OUT. BTIGAPC
function is designed for receiving up to 16 booleans input locally. If the BLOCK
input is activated, it will freeze the output at the last value.
Values of each of the different OUTx from function block BTIGAPC for 1≤x≤16.
The sum of the value on each INx corresponds to the integer presented on the
output OUT on the function block BTIGAPC.
Name of input
Type Default Description Value when
activated
Value when
deactivated
IN1 BOOLEAN 0 Input 1 1 0
IN2 BOOLEAN 0 Input 2 2 0
IN3 BOOLEAN 0 Input 3 4 0
IN4 BOOLEAN 0 Input 4 8 0
IN5 BOOLEAN 0 Input 5 16 0
IN6 BOOLEAN 0 Input 6 32 0
IN7 BOOLEAN 0 Input 7 64 0
IN8 BOOLEAN 0 Input 8 128 0
IN9 BOOLEAN 0 Input 9 256 0
IN10 BOOLEAN 0 Input 10 512 0
Table continues on next page
Section 14 1MRK 505 393-UEN B
Logic
308 Line differential protection RED650 2.2 IEC
Application manual
