ABB RED650 Applications Manual

Section 15 Monitoring
15.1 Measurement
GUID-9D2D47A0-FE62-4FE3-82EE-034BED82682A v1
15.1.1 Identification
SEMOD56123-2 v8
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Power system measurements CVMMXN
P, Q, S, I, U, f
SYMBOL-RR V1 EN-US
-
Phase current measurement CMMXU
I
SYMBOL-SS V1 EN-US
-
Phase-phase voltage measurement VMMXU
U
SYMBOL-UU V1 EN-US
-
Current sequence component
measurement
CMSQI
I1, I2, I0
SYMBOL-VV V1 EN-US
-
Voltage sequence component
measurement
VMSQI
U1, U2, U0
SYMBOL-TT V1 EN-US
-
Phase-neutral voltage measurement VNMMXU
U
SYMBOL-UU V1 EN-US
-
15.1.2 Application
SEMOD54488-4 v12
Measurement functions are used for power system measurement, supervision and
reporting to the local HMI, monitoring tool within PCM600 or to station level for
example, via IEC 61850. The possibility to continuously monitor measured values
of active power, reactive power, currents, voltages, frequency, power factor etc. is
vital for efficient production, transmission and distribution of electrical energy. It
1MRK 505 393-UEN B Section 15
Monitoring
Line differential protection RED650 2.2 IEC 317
Application manual
