21.2.2 Factory defined settings
M11789-39 v11
The factory defined settings are very useful for identifying a specific version and
very helpful in the case of maintenance, repair, interchanging IEDs between
different Substation Automation Systems and upgrading. The factory made settings
can not be changed by the customer. They can only be viewed. The settings are
found in the local HMI under Main menu/Diagnostics/IED status/Product
identifiers
The following identifiers are available:
• IEDProdType
• Describes the type of the IED. Example: REL650
• ProductDef
• Describes the release number from the production. Example: 2.1.0
• FirmwareVer
• Describes the firmware version.
• The firmware version can be checked from Main menu/
Diagnostics/IED status/Product identifiers
• Firmware version numbers run independently from the release
production numbers. For every release number there can be one or more
firmware versions depending on the small issues corrected in between
releases.
• ProductVer
• Describes the product version. Example: 2.1.0
1
is the Major version of the manufactured product this means, new platform of the
product
2 is the Minor version of the manufactured product this means, new functions or new
hardware added to the product
3 is the Major revision of the manufactured product this means, functions or hardware
is either changed or enhanced in the product
• IEDMainFunType
• Main function type code according to IEC 60870-5-103. Example: 128
(meaning line protection).
• SerialNo
• OrderingNo
• ProductionDate
21.3 Measured value expander block RANGE_XP
SEMOD52451-1 v2
Section 21 1MRK 505 393-UEN B
Basic IED functions
404 Line differential protection RED650 2.2 IEC
Application manual
