21.6.1 Application
SEMOD56004-4 v3
The analog summation block 3PHSUM function block is used in order to get the
sum of two sets of 3 phase analog signals (of the same type) for those IED
functions that might need it.
21.6.2 Setting guidelines
SEMOD56006-4 v7
The summation block receives the three-phase signals from SMAI blocks. The
summation block has several settings.
SummationType: Summation type (Group 1 + Group 2, Group 1 - Group 2, Group
2 - Group 1 or –(Group 1 + Group 2)).
DFTReference: The reference DFT block (InternalDFT Ref,DFTRefGrp1 or
External DFT ref) .
DFTRefGrp1: This setting means use own internal adaptive DFT reference ( this
setting makes the SUM3PH self DFT adaptive, that is, it will use the measured
frequency for the summation signal to adapt DFT).
InternalDFTRef: Gives fixed window DFT (to nominal system frequency).
ExternalDFTRef: This setting means that the DFT samples-per-cycle (adaptive
DFT) will be controlled by SMAI1 SPFCOUT.
FreqMeasMinVal: The minimum value of the voltage for which the frequency is
calculated, expressed as percent of UBasebase voltage setting (for each instance x).
GlobalBaseSel: Selects the global base value group used by the function to define
(IBase), (UBase) and (SBase).
21.7 Global base values GBASVAL
GUID-2FDB0A2C-10FE-4954-B6E4-9DA2EEEF1668 v1
21.7.1 Identification
GUID-0D5405BE-E669-44C8-A208-3A4C86D39115 v3
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Global base values GBASVAL - -
21.7.2 Application
GUID-D58ECA9A-9771-443D-BF84-8EF582A346BF v4
Global base values function (GBASVAL) is used to provide global values,
common for all applicable functions within the IED. One set of global values
1MRK 505 393-UEN B Section 21
Basic IED functions
Line differential protection RED650 2.2 IEC 407
Application manual
