ABB REF615 - Page 127

Table 39: Serial communication settings
Parameter Values (Range) Unit Step Default Description
Fiber mode 0=No fiber
1=Fiber light ON loop
2=Fiber light OFF loop
3=Fiber light ON star
4=Fiber light OFF star
0=No fiber Fiber mode for COM1
Serial mode 1=RS485 2Wire
2=RS485 4Wire
3=RS232 no handshake
4=RS232 with
handshake
1=RS485 2Wire Serial mode for COM1
CTS delay 0...60000 0 CTS delay for COM1
RTS delay 0...60000 0 RTS delay for COM1
Baudrate 1=300
2=600
3=1200
4=2400
5=4800
6=9600
7=19200
8=38400
9=57600
10=115200
6=9600 Baudrate for COM1
Table 40: Serial communication settings
Parameter
Values (Range) Unit Step Default Description
Fiber mode 0=No fiber
1=Fiber light ON loop
2=Fiber light OFF loop
3=Fiber light ON star
4=Fiber light OFF star
0=No fiber Fiber mode for COM2
Serial mode 1=RS485 2Wire
2=RS485 4Wire
3=RS232 no handshake
4=RS232 with handshake
1=RS485 2Wire Serial mode for
COM2
CTS delay 0...60000 0 CTS delay for COM2
RTS delay 0...60000 0 RTS delay for COM2
Baudrate 1=300
2=600
3=1200
4=2400
5=4800
6=9600
7=19200
8=38400
9=57600
10=115200
6=9600 Baudrate for COM2
1MRS756378 D Section 4
Basic functions
REF615 121
Application Manual
