Table 42: Generic timers, TPGAPC1...4
Parameter Values (Range) Unit Step Default Description
Pulse time 0...60000 ms 1 150 Minimum
pulse time
Table 43: X100 PSM binary output signals
Name Type Default Description
X100-PO1 BOOLEAN 0=False Connectors 6-7
X100-PO2 BOOLEAN 0=False Connectors 8-9
X100-SO1 BOOLEAN 0=False Connectors
10c-11nc-12no
X100-SO2 BOOLEAN 0=False Connectors 13c-14no
X100-PO3 BOOLEAN 0=False Connectors
15-17/18-19
X100-PO4 BOOLEAN 0=False Connectors
20-22/23-24
Table 44: X110 BIO binary output signals
Name
Type Default Description
X110-SO1 BOOLEAN 0=False Connectors
14c-15no-16nc
X110-SO2 BOOLEAN 0=False Connectors
17c-18no-19nc
X110-SO3 BOOLEAN 0=False Connectors
20c-21no-22nc
X110-SO4 BOOLEAN 0=False Connectors 23-24
Table 45: X110 BIO binary input signals
Name
Type Description
X110-Input 1 BOOLEAN Connectors 1-2
X110-Input 2 BOOLEAN Connectors 3-4
X110-Input 3 BOOLEAN Connectors 5-6c
X110-Input 4 BOOLEAN Connectors 7-6c
X110-Input 5 BOOLEAN Connectors 8-9c
X110-Input 6 BOOLEAN Connectors 10-9c
X110-Input 7 BOOLEAN Connectors 11-12c
X110-Input 8 BOOLEAN Connectors 13-12c
