ABB RET670 Product Guide

Analog input system #9 Notes and Rules
Compression terminals A
Ringlug terminals B
First TRM, 9I+3U 1A, 110/220V 3 Note: Not in A25
First TRM, 9I+3U 5A, 110/220V 4 Note: Not in A25
First TRM, 5I, 1A+4I, 5A+3U, 110/220V 5 Note: Not in A25
First TRM, 6I+6U 1A, 100/220V 6 Note: Only for A25
First TRM, 6I+6U 5A, 100/220V 7 Note: Only for A25
No second TRM included X0 Note: A40/B30/B40 must include a
second TRM
Compression terminals A
Ringlug terminals B
Second TRM, 12I, 1A, 100/220V 1 Note: Only for A30
Second TRM, 12I, 5A, 100/220V 2 Note: Only for A30
Second TRM, 9I+3U 1A, 110/220V 3 Note: Not in A25
Second TRM, 9I+3U 5A, 110/220V 4 Note: Not in A25
Second TRM, 5I, 1A+4I, 5A+3U, 110/220V 5 Note: Not in A25
Second TRM, 6I+6U 1A, 100/220V 6 Note: Only for A25/A30
Second TRM, 6I+6U 5A, 100/220V 7 Note: Only for A25/A30
Second TRM, 6I, 1A, 110/220V 8 Note: Only for A30
Second TRM, 6I, 5A, 5A, 110/220V 9 Note: Only for A30
Second TRM, 7I+5U 1A, 110/220V 12 Note: Only for A30
Second TRM, 7I+5U 5A, 110/220V 13 Note: Only for A30
Selection for position #9.
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
118 ABB

ABB RET670 Specifications

General

Rated Frequency	50/60 Hz
Inputs	Analog and binary inputs
Application	Protection of power systems
Communication Protocols	IEC 61850, DNP3, Modbus
Operating Temperature Range	-25°C to +55°C
Mounting	Rack mounted
Number of Binary Inputs	Up to 48
Number of Binary Outputs	32
Protection Functions	Overcurrent Protection
Outputs	Binary outputs
Enclosure	IP 54
Type	Line Differential Protection
Number of Analog Inputs	24
