112 System Manual SCK Gas Sampling System 42/23-81 EN Rev. 4
Overview: Start-up
Proceed as follows to start up the gas sampling system:
Step Procedure Instructions in ...
1
Check installation for proper
condition.
Installation check on page
113
2
Fill cooling water and check
water-tightness of the cooling-
water circuit.
Preparing the cooling-
water circuit on page 114
3
Check enclosed compressed-air
supply, fill oiler.
Preparing the com-
pressed-air supply on
page 116
4
Switch on the gas sampling sys-
tem.
Activation on page 118
5
After switching on: vent cooling-
water circuit.
After switching on: Work-
ing on the cooling module
on page 121
6
Check pneumatic system with the
aid of the compressed-air switch
in the pneumatic box.
Checking the pneumatic
system on page 123
7
In the control cabinet: check
frequency converter settings and
correct if necessary.
Checking frequency con-
verter settings on page
124
8
Check operating parameters of
the gas sampling system and
correct if necessary.
Checking/correcting oper-
ating parameters on page
127
9
Only if using probe H:
 check current monitoring relay
settings.
 Check probe heating power
supply.
Checks to perform when
using probe H on page
128
10
Insert the probe for the first time,
then adjust the speed of the
probe during operation, adjust oil
delivery rate on the compressed-
air oiler, and check direction of
rotation of the heat exchanger.
Inserting the probe and
switching to automatic
mode on page 131
