ABB SCK - Transporting the System Within the Company

42/23-81 EN Rev. 4 System Manual SCK Gas Sampling System 89
Unpacking the system
Risk of injury in the area of the gas sampling system due to moving or fall-
ing parts, anti-freeze, lubricating oil
Wear general personal protective equipment:
 Closed overalls with long trousers and long sleeves
 Safety shoes
 Safety gloves suitable for mechanical work
 Safety glasses
 Protective helmet
 If necessary, additional protective equipment if prescribed by the operator.
Danger of crushing when lifting or lowering the transport unit
 Only appropriately trained personnel may transport the transport units and only
with the aid of the recommended transport equipment.
 Do not stand under suspended loads.
 Follow the transport instructions in these operating instructions carefully.
Perform the following steps to unpack the system:
Step Procedure
1
Remove outer packaging:
 Transport crate
 Tensioning straps
 Cardboard, films and wooden parts
2
Undo fasteners holding the system parts on the pallet.
3
Lift system parts off the pallet with a crane, fork-lift truck or
hand lift (observe transport recommendations in Transport-
ing the system in the company on page 87).
Note: The retractor must not be transported with a fork-lift
truck.
4
Dispose of packaging material in accordance with the na-
tional regulations.
5
Transport system parts to the place of installation (see
Transporting the system in the company on page 87).
Mechanical and
material dangers
Heavy transport units
Instructions
