42/23-81 EN Rev. 4 System Manual SCK Gas Sampling System 13
The gas sampling system can be identified by means of the product number on the
nameplate and the following table:
Product number
23919-0-
Value Characteristic Version
1st digit 1
Application SCK
2nd-4th digit 0
n.a.
5th digit 0
Compressed-air supply w/o compressed-air tank
1
with compressed-air tank
6th digit 1
Special type and length 60S; 1.5 m
2
60S; 2 m
3
60S; 2.5 m
4
60S; 3 m
5
60S; 3.5 m
6
H; 1.5 m
7
H; 2 m
8
H; 2.5 m
9
H; 3 m
A
H; 3.5 m
7th digit 1
Retractor Standard retractor 2.5 m
2
Standard retractor 3.5 m
3
Retractor with special length
8th digit 1
Sample gas line prepared for TBL01-C
2
prepared for heated sample gas line
3
prepared for unheated sample gas line
9th digit 0
n.a.
10th digit 1
Power supply 230 V/400 V, 50 Hz
2
230 V/400 V, 60 Hz
3
120 V/208 V, 60 Hz (incl. transformer)
4
230 V/400 V, 50 Hz prep. for UPS
5
230 V/400 V, 60 Hz prep. for UPS
6
120 V/208 V, 60 Hz (incl. transformer) prep.
for UPS
11th digit 1
External signal transfer Status signals as relay contacts
2
Profibus
3
Signals as relay contacts + Profibus
4
Connection to ACX via Modbus
5
Connection to ACX + signals as relay contact
12th digit 1
Certificates CE design
2
CSA design
Unique identification
