228 System Manual SCK Gas Sampling System 42/23-81 EN Rev. 4
How to disassemble the gas sampling system:
Step Procedure
1
Clean the whole system roughly with compressed air and/or brush.
2
Remove oil from compressed-air oiler and dispose of it in accord-
ance with national regulations.
Note: Observe safety and disposal regulations for the particular
oil.
3
Label all connection lines to prevent confusion.
4
Detach connection lines.
5
Unscrew fastening screws on cooling module and control cabinet
and transport modules away. Perform the same steps for the
transformer and compressed-air tank (if present).
6
Suspend probe retractor at its attachment points using suitable
lifting gear.
Note: Pay particular attention to suitable fastening points for the
lifting equipment on the system. Observe relevant local regula-
tions.
7
Unscrew and remove fastening screws on mounting flange and
attachment points.
8
Using lifting gear, lower probe retractor until you can screw on the
enclosed transport supports.
9
Place probe retractor on ground and secure from falling over.
The following table shows further procedure:
If the system ... follow the following instructions:
is to be stored for a pro-
longed period
Storing the system on page 229.
is to be disposed of Disposing of the system on page 231.
is to be relocated
Transporting the system in the company on page
87.
is to be unpacked and
transported to another
place
Do not transport the probe retractor without
transport supports.
Use adequately load-bearing and rigid pallets.
Use suitably sized transport crates for longer-
distance transports.
Fasten sampling probe firmly on retractor if it
is not being demounted.
Note:
The retractor must not be transported by fork-lift
truck without suitable additional transport pack-
aging.
is to be put back into opera-
tion
Start-up on page 111.
Instructions
Further procedure
