Appendix A Specifications
A.1 Technical Specifications
Table A.1: Technical Specifications
ValueProperty
IR versions: 320 -1100 nm peak sensitivity @ 920 nmOptical spectrum
UV versions: 210 - 360 nm peak sensitivity @ 280 nm
UVIR versions: Combination of above IR and UV sensitivities
PYR: Dual colors IR
IR versions: Si photodiodeOptical sensor technology
UV versions: SiC photodiode
UVIR versions: One Si and one SiC photodiodes
PYR: Si Photodiode
24V
DC
(-25%, +20% = 18 - 29V
DC
)Power supply voltage
150mA typicalPower supply current
3.6W typical and 4W maximumPower consumption
6A peak and 2ms settling timeInrush current
AllowedHot insertion/removal
Contacts: 1 NO, for each relayFlame-relay
50 V
AC
/1.5A cycles 100,000Safe-relay
48 V
DC
/300 mA
30 V
DC
/1.5A
Minimum load 10mA, 5V
DC
0.2s to 4.0s at 0.1s increments (configurable setting)Flame-relay drop-out time
2s default
0.2s to 10s at 0.1s increments (configurable setting)Flame-relay pull-in time
2s default
4 - 20 mA (R load <= 500)Analog output (4-20mA)
Galvanically isolated
