A.3 Galvanic Isolation Specifications
Table A.3: Galvanic Isolation Specifications
Test Severity levelsCAN/CSA-E60730-1 and UL 60730-1
500V
AC
between enclosure earth and all terminal blocks (except relay
contacts and +24V
DC
terminal).
Rated impulse voltage
1500V
AC
between enclosure earth and relay contacts and between relay
contacts
A.4 EMC Specifications
Follow the below standards:
– IEC 61000-6-2
– IEC 61000-6-4
– IEC 61000-4-29
– IEC 61326-3-1
– IEC 60730-1/CAN/CSA E60730-1
– EN 298 and EN 13611
Table A.4: EMC Specifications - 1
Design Level/Acceptance CriteriaStandardsCategory/Purpose
± 8 KV contact dischargeIEC 61000-4-2Electro Static Discharge (ESD) Immunity
± 15 KV air dischargeIEC 61326-3-1
EN 13611
80 - 1000MHz 20V/mIEC 61000-4-3Radiated, Radio-Frequency, and
Electromagnetic Field Immunity
1400 - 6000MHz 10V/mIEC 61326-3-1
80% Amplitude ModulatedEN 13611
(1 KHz, sin.)
Relay contacts:IEC 61000-4-4Electrical Fast Transient (Burst) Immunity
3 kV (5/50ns, 5 kHz)IEC 61326-3-1
Others and Earth:EN 13611
2 kV (5/50ns, 5 kHz)
Relay contacts:IEC 61000-4-5Surge Immunity
2 kV (line to line)IEC 61326-3-1
