The wiring methods available allow for quick plug connectorized cable, versions “Q” and
“QC” or for direct cable connection, version “T” and “TL”.
Refer to Table 1.1 for complete SF910i product coding.
Refer datasheet for a complete listing of ordering codes.
Table 1.1: SF910i Type Product Coding
SF910i Type Product Coding
x
4
x
3
x
2
x
1
SF910i
XXXX (Reserved for
other characteristics,
with letters or numbers
or the combination, up
to 4, which are not
relevant to Ex-proof
protection mode. For
example, “L” means lite
version and “S” means
sweden manufactured
products)
T (Direct wiring - Ex)
TL (Direct wiring - IP66)
QC (Quick plug in - Ex)
Q (Quick plug in - IP66)
QE (Quick plug in)
TX (Direct wiring - Ex -
SS316 case)
IR (Infrared Sensor)
UV (Ultraviolet Sensor)
UVIR (UV IR Dual
Sensor)
PYR (Dual IR Sensor)
LOS (Line Of Sight)
FOC (Fiber Optic Cable)
Ex version of the FOC assemblies (that is, SF910i-FOC-X2-T or SF910i-FOC-X2-QC)
must be mandatory assembled with ABB Ex certified fiber optic. Refer ABB fiber
optic cable part numbers:
– EC-DWG-G041MEC020
– EC-DWG-G041MEC021
– EC-DWG-G041MEC022
The minimum length of fiber cable must be one meter.
If otherwise, the Ex product certificate is void.
1.3.4 Fiber Optics
Refer to the product data sheet for a complete listing of fiber optic assemblies and related
mounting hardware. SF910i use existed SF810i fiber, aovid to re-create a sets of new
fiber names.
Table 1.2: Fiber Optic Cable Assembly - Product Coding
x
3
x
2
x
1
XXXXIR (Infrared Sensor)FOARE (Fiber optic cable and
rigid external guide pipe)
SF810
