ABB Uvisor SF910i - Cabling

F.2 Cabling
SF910i can be wired to external devices using standard cables available on the market.
The following tables specifies the technical requirement for the SF910i cables except
SF910i-L.
Note that in this case, ABB does not specify mechanical properties, global cross sections,
fire resistance properties, and so on. The following are the minimum electrical
requirements.
Table F.1: 24 V
DC
Power Supply
PairType
1 mm
2
eachConductor(s) section
CopperConductor(s) material
Conductor 1: redColors
Conductor 2: black
Not requiredShield
<= 20 Ohm/Km (at 20ºC)Conductor resistance
>= 1000 MOhm x Km (at 20ºC)Isolation resistance
< 50V
DC
Working voltage
Table F.2: Relays Contacts
Three ConductorsType
0.5mm
2
eachConductor(s) section
CopperConductor(s) material
Conductor 1: OrangeColors
Conductor 2: Light-blue
Conductor 3: Pink
Not requiredShield
<= 20 Ohm/Km (at 20ºC)Conductor resistance
>= 1000 MOhm x Km (at 20ºC)Isolation resistance
Up to 50V
AC
Working voltage
8VZZ005286 B 165
F Cables
F.2 Cabling
