7 Operating Display
In Normal-Mode, the SF910i provides a real-time display of operating values. Using UP
and DOWN buttons, it is possible to navigate through the current values as explained
below.
7.1 Measured-Values Displays
Measured-Values and their related quality values can be viewed in several different
formats:
– Bar-type displays
– Numeric values
– A combination of both number and bar-type
Figure 7.1: Sample Display in Normal-Mode
