Table F.5: Analog Output
(Continued)
Shielded Twisted PairType
Conductor 2: white/black
YesShield
<= 88.6 Ohm/Km (at 20ºC)Conductor resistance
>= 1000 MOhm x Km (at 20ºC)Isolation resistance
< 50V
DC
Working voltage
F.3 ABB Special Cables
The number of conductors required for wiring the SF910i to the associated external
devices are dependent on the functions utilized by the scanner.
All SF910i products use ABB standard cable part number: SF910i-CBL16, which is made
up of 16+1 (Sh) conductors grouped according to the functional feature of the Flame
Scanner. The table below reports individual conductor size, color, circular connector pin,
SF910i TB connection, and relevant signal.
