Table B.4: Proposed Initial Settings for GT and Side Igniter Applications
(Continued)
Side IgnitorGas TurbineApplication Description
OffOffAC Amplitude
BABAFunction Set
IGNGTFunction Identifier
105Intensity Pickup
105Intensity Dropout
Intsensity Hi
155Frequency Pickup
155Frequency Dropout
Frequency Hi
AC Pickup
AC Dropout
AC Hi
1520Quality Norm Intensity
Quality Norm Intensity Hi
1520Quality Norm Frequency
Quality Norm Frequency Hi
Quality Norm AC
Quality Norm Frequency AC
5555Frequency Sensitivity
50Intensity Smoothing
80Frequency Smoothing
AC Smoothing
20Delay on Dropout
Delay on Pickup
125125Maximum Frequency
