ABB XAC22682 - Table 53: Cartridge Group with Part Numbers

Operation Manual / 4 Product description / A200-L
12 Spare parts / 12.3 View of cartridge group with part numbers
© Copyright 2020 ABB. All rights reserved. HZTL4036_EN Rev.Q July 2020
Cartridge group
Part number Designation
21000 Turbine
25000 Compressor wheel
25008 Threaded stud
25009 Ring nut
25012 Spinner nose cone
25013 Screw
25014 Washer
32001 Thrust bearing
32101 Radial bearing, compressor end
32102 Radial bearing, turbine end
32105 Floating disc
32106 Axial bearing
32109 Sealing disc
32159 Locking screw
32174 O-ring
42001 Bearing casing
42008 Socket screw
42011 O-ring
42015 Sealing cover
42039 Hexagon-head screw
42041 Gasket
42059 Hexagon-head screw
42064 Hexagon-head screw
42185 Socket screw
42186 O-ring
42295 Pressure adjusting unit
42300 Partition wall
42305 O-ring
42306 O-ring
42307 O-ring
42320 Socket screw
42458 Blind flange
86505 Speed sensor
86506 (in the customer spare part set) O-ring
Table53: Cartridge group with part numbers
Page 107 / 110
