ABB XAC22682 - Fig. 4: Fitting the Lifting Gear

To Next Page

To Previous Page

Operation Manual / 4 Product description / A200-L

2 Removal and installation / 2.2 Removing the turbocharger

Fig.4: Fitting the lifting gear

u Loosen fixing screws on compressor-end and turbine-end foot.

u Lift turbocharger from engine and put down in a suitable location.

u Cover oil connections.

Page 9 / 110
