ABL eMS home User Manual

Appendix – Data Storage app – CSV export format |
55
Description OBIS code Unit
Apparent energy- 1-0:10.8.0*255 vah
Power factor 1-0:13.4.0*255 none
Power factor min 1-0:13.3.0*255 none
Power factor max 1-0:13.6.0*255 none
Supply frequency 1-0:14.4.0*255 Hz
Supply frequency min 1-0:14.3.0*255 Hz
Supply frequency max 1-0:14.6.0*255 Hz
Active power+ (L1) 1-0:21.4.0*255 W
Active power+ (L1) min 1-0:21.3.0*255 W
Active power+ (L1) max 1-0:21.6.0*255 W
Active energy+ (L1) 1-0:21.8.0*255 Wh
Active power- (L1) 1-0:22.4.0*255 W
Active power- (L1) min 1-0:22.3.0*255 W
Active power- (L1) max 1-0:22.6.0*255 W
Active energy- (L1) 1-0:22.8.0*255 Wh
Reactive power+ (L1) 1-0:23.4.0*255 var
Reactive power+ (L1) min 1-0:23.3.0*255 var
Reactive power+ (L1) max 1-0:23.6.0*255 var
Reactive energy+ (L1) 1-0:23.8.0*255 varh
Reactive power- (L1) 1-0:24.4.0*255 var
Reactive power- (L1) min 1-0:24.3.0*255 var
Reactive power- (L1) max 1-0:24.6.0*255 var
Reactive energy- (L1) 1-0:24.8.0*255 varh
Apparent power+ (L1) 1-0:29.4.0*255 VA
Apparent power+ (L1) min 1-0:29.3.0*255 VA
Apparent power+ (L1) max 1-0:29.6.0*255 VA
Apparent energy+ (L1) 1-0:29.8.0*255 vah
Apparent power- (L1) 1-0:30.4.0*255 VA
Apparent power- (L1) min 1-0:30.3.0*255 VA
Apparent power- (L1) max 1-0:30.6.0*255 VA
Apparent energy- (L1) 1-0:30.8.0*255 vah
Current (L1) 1-0:31.4.0*255 A
Current (L1) min 1-0:31.3.0*255 A
Current (L1) max 1-0:31.6.0*255 A
Voltage (L1) 1-0:32.4.0*255 V

ABL eMS home Specifications

General

Communication Interface	Ethernet
Protocols	Modbus TCP
Storage Temperature	-40°C to +70°C
Humidity	5% to 95% (non-condensing)
Certification	CE
