ABL eMS home User Manual

| Appendix – Data Storage app – CSV export format
56
Description OBIS code Unit
Voltage (L1) min 1-0:32.3.0*255 V
Voltage (L1) max 1-0:32.6.0*255 V
Power factor (L1) 1-0:33.4.0*255 none
Power factor (L1) min 1-0:33.3.0*255 none
Power factor (L1) max 1-0:33.6.0*255 none
Active power+ (L2) 1-0:41.4.0*255 W
Active power+ (L2) min 1-0:41.3.0*255 W
Active power+ (L2) max 1-0:41.6.0*255 W
Active energy+ (L2) 1-0:41.8.0*255 Wh
Active power- (L2) 1-0:42.4.0*255 W
Active power- (L2) min 1-0:42.3.0*255 W
Active power- (L2) max 1-0:42.6.0*255 W
Active energy- (L2) 1-0:42.8.0*255 Wh
Reactive power+ (L2) 1-0:43.4.0*255 var
Reactive power+ (L2) min 1-0:43.3.0*255 var
Reactive power+ (L2) max 1-0:43.6.0*255 var
Reactive energy+ (L2) 1-0:43.8.0*255 varh
Reactive power- (L2) 1-0:44.4.0*255 var
Reactive power- (L2) min 1-0:44.3.0*255 var
Reactive power- (L2) max 1-0:44.6.0*255 var
Reactive energy- (L2) 1-0:44.8.0*255 varh
Apparent power+ (L2) 1-0:49.4.0*255 VA
Apparent power+ (L2) min 1-0:49.3.0*255 VA
Apparent power+ (L2) max 1-0:49.6.0*255 VA
Apparent energy+ (L2) 1-0:49.8.0*255 vah
Apparent power- (L2) 1-0:50.4.0*255 VA
Apparent power- (L2) min 1-0:50.3.0*255 VA
Apparent power- (L2) max 1-0:50.6.0*255 VA
Apparent energy- (L2) 1-0:50.8.0*255 vah
Current (L2) 1-0:51.4.0*255 A
Current (L2) min 1-0:51.3.0*255 A
Current (L2) max 1-0:51.6.0*255 A
Voltage (L2) 1-0:52.4.0*255 V
Voltage (L2) min 1-0:52.3.0*255 V
Voltage (L2) max 1-0:52.6.0*255 V

ABL eMS home Specifications

General

Communication Interface	Ethernet
Protocols	Modbus TCP
Storage Temperature	-40°C to +70°C
Humidity	5% to 95% (non-condensing)
Certification	CE
