ABL eMS home User Manual

Appendix – Data Storage app – CSV export format |
57
Description OBIS code Unit
Power factor (L2) 1-0:53.4.0*255 none
Power factor (L2) min 1-0:53.3.0*255 none
Power factor (L2) max 1-0:53.6.0*255 none
Active power+ (L3) 1-0:61.4.0*255 W
Active power+ (L3) min 1-0:61.3.0*255 W
Active power+ (L3) max 1-0:61.6.0*255 W
Active energy+ (L3) 1-0:61.8.0*255 Wh
Active power- (L3) 1-0:62.4.0*255 W
Active power- (L3) min 1-0:62.3.0*255 W
Active power- (L3) max 1-0:62.6.0*255 W
Active energy- (L3) 1-0:62.8.0*255 Wh
Reactive power+ (L3) 1-0:63.4.0*255 var
Reactive power+ (L3) min 1-0:63.3.0*255 var
Reactive power+ (L3) max 1-0:63.6.0*255 var
Reactive energy+ (L3) 1-0:63.8.0*255 varh
Reactive power- (L3) 1-0:64.4.0*255 var
Reactive power- (L3) min 1-0:64.3.0*255 var
Reactive power- (L3) max 1-0:64.6.0*255 var
Reactive energy- (L3) 1-0:64.8.0*255 varh
Apparent power+ (L3) 1-0:69.4.0*255 VA
Apparent power+ (L3) min 1-0:69.3.0*255 VA
Apparent power+ (L3) max 1-0:69.6.0*255 VA
Apparent energy+ (L3) 1-0:69.8.0*255 vah
Apparent power- (L3) 1-0:70.4.0*255 VA
Apparent power- (L3) min 1-0:70.3.0*255 VA
Apparent power- (L3) max 1-0:70.6.0*255 VA
Apparent energy- (L3) 1-0:70.8.0*255 vah
Current (L3) 1-0:71.4.0*255 A
Current (L3) min 1-0:71.3.0*255 A
Current (L3) max 1-0:71.6.0*255 A
Voltage (L3) 1-0:72.4.0*255 V
Voltage (L3) min 1-0:72.3.0*255 V
Voltage (L3) max 1-0:72.6.0*255 V
Power factor (L3) 1-0:73.4.0*255 none

ABL eMS home Specifications

General

Communication Interface	Ethernet
Protocols	Modbus TCP
Storage Temperature	-40°C to +70°C
Humidity	5% to 95% (non-condensing)
Certification	CE
