Abov MC96F6432Q User Manual

MC96F6432
14 June 22, 2018 Ver. 2.9
1.2 Features
• CPU
- 8-bit CISC Core (8051 Compatible)
• ROM (FLASH) Capacity
- 32 Kbytes
- Flash with self read/write capability
- On chip debug and In-system programming (ISP)
- Endurance : 100,000 times
- Retention : 10 years
• 256 bytes IRAM
• 768 bytes XRAM
- (27 bytes including LCD display RAM)
• General Purpose I/O (GPIO)
- Normal I/O : 9 Ports
(P0[2:0], P5[5:0])
- LCD shared I/O : 33 Ports
(P0[7:3], P1, P2, P3, P4)
• Basic Interval Timer (BIT)
- 8-bit × 1ch
- Watch Dog Timer (WDT)
- 8-bit × 1ch
- 5kHz internal RC oscillator
• Timer/ Counter
- 8-bit × 1ch (T0), 16-bit × 2ch (T1/T2)
- 8-bit × 2ch (T3/T4) or 16-bit × 1ch (T3)
• Programmable Pulse Generation
- Pulse generation (by T1/T2)
- 8-bit PWM (by T0)
- 6-ch 10-bit PWM for Motor (by T4)
• Watch Timer (WT)
- 3.91ms/0.25s/0.5s/1s/1min interval at 32.768kHz
• Buzzer
- 8-bit × 1ch
• SPI 2
- 8-bit × 1ch
• USI0/1 (UART + SPI + I2C)
- 8-bit UART × 2ch, 8-bit SPI × 2ch and I2C × 2ch
• 12-bit A/D Converter
- 16 Input channels
• LCD Driver
- 21 Segments and 8 Common terminals
- Internal or external resistor bias
- 1/2, 1/3, 1/4, 1/5, 1/6 and 1/8 duty selectable
- Resistor Bias and 16-step contrast control
• Power On Reset
- Reset release level (1.4V)
• Low Voltage Reset
- 14 level detect (1.60V/ 2.00V/ 2.10V/ 2.20V/
2.32V/ 2.44V/ 2.59V/ 2.75V/ 2.93V/ 3.14V/
3.38V/ 3.67V/ 4.00V/ 4.40V)
• Low Voltage Indicator
- 13 level detect (2.00V/ 2.10V/ 2.20V/ 2.32V/
2.44V/ 2.59V/ 2.75V/ 2.93V/ 3.14V/ 3.38V/
3.67V/ 4.00V/ 4.40V)
• Interrupt Sources
- External Interrupts
(EXINT0~7, EINT8, EINT10, EINT11, EINT12)
(12)
- Timer(0/1/2/3/4) (5)
- WDT (1)
- BIT (1)
- WT (1)
- SPI 2 (1)
- USI0/1 (6)
- ADC (1)
• Internal RC Oscillator
- Infernal RC frequency:
16MHz ±1.0% (T
A
= 0 ~ +50°C)
• Power Down Mode
- STOP, IDLE mode
• Operating Voltage and Frequency
- 1.8V ~ 5.5V (@32 ~ 38kHz with crystal)
- 1.8V ~ 5.5V (@0.4 ~ 4.2MHz with crystal)
- 2.7V ~ 5.5V (@0.4 ~ 10.0MHz with crystal)
- 3.0V ~ 5.5V (@0.4 ~ 12.0MHz with crystal)
- 1.8V ~ 5.5V (@0.5 ~ 8.0MHz with Internal RC)
- 2.0V ~ 5.5V (@0.5 ~ 16.0MHz with Internal RC)
- Voltage dropout converter included for core
• Minimum Instruction Execution Time
- 125us (@ 16MHz main clock)
- 61us (@t 32.768kHz sub clock)
• Operating Temperature: – 40 ~ + 85℃
• Oscillator Type
- 0.4-12MHz Crystal or Ceramic for main clock
- 32.768kHz Crystal for sub clock
• Package Type
- 44 MQFP-1010
- 32 LQFP
- 32 SOP
- 28 SOP
- Pb-free package
