9.8 P5 Port
9.8.1 P5 Port Description
P5 is 6-bit I/O port. P5 control registers consist of P5 data register (P5), P5 direction register (P5IO) and P5
pull-up resistor selection register (P5PU) . Refer to the port function selection registers for the P5 function
selection.
9.8.2 Register description for P5
P5 (P5 Data Register) : B0H
7
6
5
4
3
2
1
0
–
–
P55
P54
P53
P52
P51
P50
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
P5[5:0]
I/O Data
Note) Do not use the “direct bit test and branch” instruction for input port, more detail information is at
Appendix B.
Example) Avoid direct input port bit test and branch condition as below
If(P50) → if(P5 & 0x01)
P5IO (P5 Direction Register) : D1H
7
6
5
4
3
2
1
0
–
–
P55IO
P54IO
P53IO
P52IO
P51IO
P50IO
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
P5IO[5:0]
P5 Data I/O Direction
0
Input
1
Output
NOTE: EC0/EINT8/EINT10/BLNK function possible when input
P5PU (P5 Pull-up Resistor Selection Register) : 95H
7
6
5
4
3
2
1
0
–
–
P55PU
P54PU
P53PU
P52PU
P51PU
P50PU
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
P5PU[5:0]
Configure Pull-up Resistor of P5 Port
0
Disable
1
Enable
