MC96F6432
June 22, 2018 Ver. 2.9 13
MC96F6432
CMOS SINGLE-CHIP 8-BIT MICROCONTROLLER
WITH 12-BIT A/D CONVERTER
1. Overview
1.1 Description
The MC96F6432 is an advanced CMOS 8-bit microcontroller with 32k bytes of FLASH. This is powerful
microcontroller which provides a highly flexible and cost effective solution to many embedded control applications.
This provides the following features : 32 Kbytes of FLASH, 256 bytes of IRAM, 768 bytes of XRAM , general
purpose I/O, basic interval timer, watchdog timer, 8/16-bit timer/counter, 16-bit PPG output, 8-bit PWM output,
10-bit PWM output, watch timer, buzzer driving port, SPI, USI, 12-bit A/D converter, LCD driver, on-chip POR,
LVR, LVI, on-chip oscillator and clock circuitry. The MC96F6432 also supports power saving modes to reduce
power consumption.
Device Name
FLASH
XRAM
IRAM
ADC
I/O PORT
Package
MC96F6432L
MC96F6432Q
MC96F6332L
MC96F6332D
MC96F6332M
32 Kbytes
768 bytes
256 bytes
16 channel
16 channel
12 channel
12 channel
11 channel
42
42
30
30
26
48 LQFP-0707
44 MQFP
32 LQFP
32 SOP
28 SOP
