VL-TH – Thermistor / Resistor Inputs
Besides the on-board thermistor channel, the VL-TH logger has seven external channels used to
measure the external thermistors or resistors. The following figure illustrates the correct input
connections:
CH1
A2/E
A1
COM
CH7
CH6
COM
CH5
CH4
COM
CH3
CH2
COM
Thermistor
Thermistor External Input Connections
Note: All inputs must share the same common ground.
