Accsense VersaLog Data Loggers User’s Manual Page 30
The following table lists all available built-in equations for all channel types:
Channel Type
Equation Name
Equation Description
Internal-Thermistor
Temperature
Temperature
External-Thermistor
Temperature
Temperature
0-20 VDC
VoltageDC
Voltage DC
-5 to +5 VDC
VoltageDC
Voltage DC
0-20 mA DC
CurrentDC
Current DC
Thermocouple
Rage1:
-8 to +73 mV
ThermocoupleE
ThermocoupleJ
ThermocoupleK
ThermocoupleN
ThermocoupleT
VoltageDC
Thermocouple E
Thermocouple J
Thermocouple K
Thermocouple N
Thermocouple T
Voltage DC
Thermocouple
Rage3:
-2 to +18 mV
ThermocoupleB
ThermocoupleE
ThermocoupleJ
ThermocoupleK
ThermocoupleN
ThermocoupleR
ThermocoupleS
ThermocoupleT
VoltageDC
Thermocouple B
Thermocouple E
Thermocouple J
Thermocouple K
Thermocouple N
Thermocouple R
Thermocouple S
Thermocouple T
Voltage DC
Pulse
Pulse
Pulse
Event
Event
Event
State
State
State
RTD
RTD_TCR385
RTD_TCR392
For TCR of 0.00385
For TCR of 0.00392
Measuring & Logging
During the session of logging, when it’s time to sample, the Accsense VersaLog data logger
measures the signal of each enabled channel, converts it to digital value and saves to the on-
board memory.
Accsense VersaLog data loggers use a group of preset parameters to decide when and how to
take in data and save it to the memory. Those parameters can be configured by VersaLog
SiteView software and their definitions are given as below:
Start Time:
This parameter specifies the date and time when the logger starts the session of logging.
