Accsense VersaLog Data Loggers User’s Manual Page 26
Event channel is used to detect the number of events that occur but not the duration of the event. In
each sampling interval period if it detects an event, it saves the event with the time stamp. The
resolution of the time stamp is the sampling interval. i.e. if there are more than one events occur
during the same sampling interval period it only saves the first event (the third period in the
diagram below). A typical application is to monitor rainfall with tipping bucket.
Pluggable terminal block for seven external
channels and alarm outputs.
Seven external channels record state changes,
event or pulse count.
Each channel can be configured as either stage,
event or pulse channel based on applications.
For Event and Pulse configuration, each
channel’s trigger detection can be configured
between Normal Open (High to Low)
