AccuEnergy AcuDC 241 User Manual

AcuDC 240 Series
www.accuenergy.com
V: 1.0 Revised: Jan. 2018
4
DC Energy & Power meters
Voltage
Current
Input Range
0~±10A(Direct Input, pick up current 0.01A)
0~±50000A(Via Shunt or Hall Effect Sensor, program-
mable range)
Shunt 50~100mV(programmable)
Hall Effect Sensor 0~±5V/0-±4V, 4~20mA/12mA±8mA
Power Consumption 2W(MAX)
Accuracy 0.2%
Digital Input
Type Dry Contact
Isolation Voltage 2500Vac
Environment
Operation Temperature -25°C ~ +70°C
Storage Temperature -40°C ~ +85°C
Humidity 5%~95%Non-condensing
Output
Relay Output (RO)
Type Mechanical contact, Form A
Max Load Voltage 250Vac/30Vdc
Max Load Current 3A
On Resistance 100mΩ (Max)
Isolation Voltage 4000Vac
Mechanical Life 5 × 106 times
Digital Output (Photo-Mos)
Load Voltage Range 0~250Vac/dc
Load Current 100mA(Max)
Max Output Frequency 25Hz, 50% duty cycle
Isolation Voltage 2500Vac
Analog Output (AO)
Load Voltage Range 4-20mA/0~20mA; 0~5V/1-5V
Load Current 0.5%
Max Output Frequency
Current type, max load resistance: 750 Ohm Voltage
type, max load current: 20 mA
