www.accuenergy.com
V: 1.0 Revised: Jan. 2018
Chapter 5: Viewing Real-Time Readings via Acuview Software
51
Raw Channel of AO1/Raw Channel of AO2: The settings are available with the X1 and X2
modules
Select the parameter (Voltage, Current, Power) you will like to send as an Analog Output.
Set the High and Low Limit based on the parameter you have selected.
Note:
• When AO parameter is set as voltage, the upper and lower limit setting range is
between 0% - 100%. E.g. it can be set as: 0% - 100%, 0% - 50% etc.
• When AO parameter is set as current or power, there are four different modes for
the upper and lower limit setting range. It can be between: 0% - +100%, 0% - -100%,
-100% - +100%, and 0% - ±100%. E.g. it can be set as: 0% - +50%, 0% - -50% etc.
• Upper Limit cannot be 0%
Other:
• You can adjust the backlight brightness under the Backlight Adjustment section. The
range is from 1 to 5.
DI 1 Type/ DI 2 Type:
Select DI 1 or DI 2 as:
• State: DI will act as a switch status monitor
• Counter: DI will act as a pulse counter.
NOTE: You can ‘import’ a saved device profile to quickly setup the meter parameters:
Click Tools->Import Device Settings, select the desired file and click ‘Open’, and after
importing successfully, click ‘Update Device’, or click Tools->Import and Update Device,
select the desired file.
You also can save the current settings to a file via the export device profile function in
‘Tools’.
5.2.2 Configure the Data Log using the meter’s onboard memory
You can set up the meter to log data on the onboard memory.
• From the left navigation panel click on the settings tab then click ‘Data Log’ to access
the data log setting page (as shown in Fig 5-5).
