Chapter 1: Introduction to AcuDC
www.accuenergy.com
1
V: 1.0 Revised: Jan. 2018
CHAPTER 1: INTRODUCTION TO THE ACUDC
1.2 Introduction and Compliance
1.2.1 Introduction
Powerful Yet Cost-Effective
AcuDC 240 series monitors DC voltage, current, power and energy. It supports bi-
directional current measurement, and also displays meter running hour and load running
hour. Analog Output applies to DCS system, industrial monitoring and control. AcuDC
240 has a combination of accurate measurement, intelligent multifunction and simple
human machine interface. The cost-effective meter fulfills the requirements of monitoring
and controlling the DC circuit.
Compact and Easy to Install
The dimensions of AcuDC 240 series meet DIN 72X72 requirements. With a mounting
depth of 65mm, the meter can even fit in small drawer type cabinets. It utilizes a self-lock
installation mechanism, eliminating the necessary of fix bolts, which makes installation or
removal quick and convenient.
User Friendly Interface
AcuDC 240 series utilizes a clear high-definition LCD screen with large characters. The
LCD screen comes with a brightness adjustable backlight, which ensures easy observation
of metering data in any environment. With a large LCD screen display, the two keys on the
meter from allow users to observe multiple parameter data at the same time. The meter
parameter settings can be set either via front panel keys or the communication port. The
Parameter settings are saved in the non-volatile EEPROM, which remains when power is
off.
1.1 Package Contents & Available Accessories
When you open the package, you will find the following items:
1. AcuDC 240 Meter X1
2. Terminal Blocks X1 - X3 (Depending on model)
3. Installation Clips X4 (Already assembled to the meter)
Available Accessories:
I/O modules (Combinations of digital I/O, analog I/O and relay output)
Current transformers
USB to Serial Converters
