www.accuenergy.com
V: 1.0 Revised: Jan. 2018
40
AcuDC 240 Series
DC Energy & Power meters
CHAPTER 4: VIEWING METERING PARAMETERS – VIA
DISPLAY
You can view different information from the metering screen. For example, you can view voltage,
current, power, energy, electric charge and clock information.
In the metering screen, press ‘F’ to go to next screen, press ‘V/A’ to go to the different windows to
view different information.
4.1 General Display on the AcuDC
AcuDC 240 normally displays the metering screen, which shows real-time measured
data, such as voltage, current, power, energy, meter clock, DI counter etc., as shown in
table 4-1.
The first screen on the metering screen shows voltage, current and power. Please note
that AcuDC241 only shows voltage and AcuDC242 only shows current. Only AcuDC243
shows voltage, current and power at the same time.
