9
On discs containing index codes, these buttons can be used to
jump to the start of an index section.
Repeat buttons (page 16, 17)
REPEAT
Repeat playback of entire disc or one track.
A B
Repeat playback of a section between two points within a
track.
17
19
20
26
Program play buttons (page 18, 19)
PROGRAM
Allows you to create a program to play only your favorite tracks
on a disc or to rearrange the tracks on a disc in any desired
sequence.
CHECK
Serves to check an entered program.
28
Direct play buttons (page 14)
Serve for specifying a track number directly for playback.
OUTPUT LEVEL control buttons
18
These buttons adjust the analog output level. The digital
principle permits adjustment of the output level in the range
from 0 dB to −60 dB (in 1-dB steps).
●
Normally the 0 dB setting should be used.
INDEX search buttons (page 15)
Pressing this button during shuffle or program playback returns
the unit to normal playback.
21
CONTINUE button (page 17, 18)
This button activates shuffle playback (all tracks on the disc
are played once in random order).
22
SHUFFLE play button (page 17)
With this button, the display can be turned off during playback.
※During processor operation (see page 22), the display cannot
be turned off.
23
DISPLAY MODE: ON/OFF button (page 12)
Serves to clear programmed tracks.
24
CLEAR button (page 19)
25
These buttons can be used during play or pause to locate a
specific point on the disc.
LANGUAGE button (page 13)
When a disc with multi-language text is inserted, this button
serves for selecting the display language.
27
TIME/TEXT selector button (page 12, 13, 19)
Cycles through the following display settings: elapsed time,
remaining track time, remaining disc time, text.
 FR (Fast Reverse)/ FF (Fast Forward)
button (page 15)

＋
Press＋toincreasetheleve
l.
Press−toincreasetheleve
l.
1-dBsteps
OUTPUTLEVEL
LEVEL（−dB）
−
LEVEL（−dB）
〈Level indication on display〉

Accuphase DP-77 Specifications

Optical Specifications

SACD wavelength	650 nm
CD wavelength	780 nm
Optical output wavelength	660 nm

Digital Processor Specifications

Sampling frequencies	32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz
High sampling frequencies	176.4kHz, 192kHz
Dynamic range	114 dB

Power

AC voltage	120V/230V 50/60Hz
Power consumption	24 W
Net weight	17.7 kg

Weight and Dimensions

Width	475 mm
Height	151 mm
Depth	397 mm
