EVO 150 Controller
49
Note: In all tables, x indicates don’t care or not used.
PLC I/O Board Inputs
Input
Connector
J1 terminal
AUXILIARY
Input
Function
(Param 52)
Switchpad
Type
(Param 51)
Action performed when input is activated
AUXILIARY
8
selects
AUTO
mode
x
Select Automatic mode (guide the web using position
feedback from sensors selected by the EDGE A, EDGE
B, or LINE / CENTERLINE inputs).
other
function
x
Select other operating functions. See description of
parameter 52.
SERVO-
CENTER
2 x x
Select Servo-Center mode (move actuator to servo-
center position).
MANUAL
1 x x Select Manual mode (stop actuator).
IN
6 x x Select Manual mode and In mode (move actuator in).
OUT
7 x x Select Manual mode and Out mode (move actuator out).
EDGE A
3
selects
AUTO
mode
x Select Input A.
other
function
x Select Input A and Automatic mode.
EDGE B
4
selects
AUTO
mode
x Select Input B.
other
function
x Select Input B and Automatic mode.
LINE /
CENTERLINE
5
selects
AUTO
mode
has
CENTERLINE
button
Select Centerline mode.
other
function
has
CENTERLINE
button
Select Centerline mode and Automatic mode.
selects
AUTO
mode
has LINE
button
Select Input C.
Note: To select Centerline mode, activate the EDGE A
and EDGE B inputs simultaneously.
other
function
has LINE
button
Select Input C and Automatic mode.
Note: To select Centerline mode, activate the EDGE A
and EDGE B inputs simultaneously.
9 x x
This is the connector COMMON. For sourcing to the
inputs, connect the - customer supplied voltage. For
sinking from the inputs, connect the + customer supplied
voltage.
