Remote Station - Guide Point Adjust
89
Introduction
The Guide Point Adjust Remote Station provides a convenient method of adjusting the system’s
guide point from a remote location.
The Guide Point Adjust Remote Station is compatible with the following controllers:
MICRO 1000, MICRO 4000 NET or EVO 150 Controllers
The Guide Point Adjust Remote Station requires an interface cable to connect to these
controllers. Cables are available in standard lengths of 12’ [3.6m], 25’ [7.6m], 50’ [15.2
m], 75’ [22.8m], and 100’ [30.5m].
The Guide Point Adjust Remote Station also requires a Serial I/O board (AUX 4249) to
connect to the EVO 150 Controller.
Note: The Remote Station –guide Point Adjust cannot be used on EVO 150 controllers with
the field bus option..
Product Specifications:
• Remote Station size (H x W x D): 2.52” [64mm] x 3.86” [98mm] x 1.41” [36mm]
• Power requirements: Supplied by controller
• Operating environment:
Maximum ambient temperature 120 deg F [48.9 deg C]
Humidity 0-90%, Non-condensing
Installation
The Remote Station can be mounted in a variety of ways. The enclosure design allows the user
to easily remove the rear housing for panel-mount applications. Refer to the application drawings
and connection diagrams on page 121 for installation information.
