AccuWeb EVO 150 - Page 79

AccuBeam 3 Digital Line Guide Sensor
77
Bit definitions:
Job Profile Offset Calibrate LED Color LED Angle Filter Threshold Pattern Scan Direction Maximum Left Minimum Left Maximum Center Minimum Center Maximum Right Minimum Right Backlight Hidden Read-Only Start-Up
Bit number
19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Hex digit
fifth fourth third second first
Hexadecimal (hex) conversion:
Bit-field Hex digit
0 0 0 0 0
0 0 0 1 1
0 0 1 0 2
0 0 1 1 3
0 1 0 0 4
0 1 0 1 5
0 1 1 0 6
0 1 1 1 7
1 0 0 0 8
1 0 0 1 9
1 0 1 0 A
1 0 1 1 B
1 1 0 0 C
1 1 0 1 D
1 1 1 0 E
1 1 1 1 F
Example: Offset, Backlight, Hidden, Read-Only, and Start-up parameters are hidden
Job Profile Offset Calibrate LED Color LED Angle Filter Threshold Pattern Scan Direction Maximum Left Minimum Left Maximum Center Minimum Center Maximum Right Minimum Right Backlight Hidden Read-Only Start-Up
Bit settings
0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1
Hex digits
2 0 0 0 F
