Introduction
The Auxiliary Remote Station is intended for systems that require two Remote Stations. The other
station must be either a Guide Point Adjust Remote Station or a Web Width Monitor Remote
Station.
The Auxiliary Remote Station is also compatible with the Digital Line Guide and provides a
conve
nient method of adjusting the Line Guide’s parameters from a remote location.
The Auxiliary Remote Station is compatible with the following controllers, sensor, and
remote
stations:
MICRO 4000 NET or MICRO 1000 Controllers
The Auxiliary Remote Station requires an interface cable to
connect to these controllers.
Cables are available in standard lengths of 12’ [3.6m], 25’ [7.6m], 50’ [15.2 m], 75’
[22.8m], and 100’ [30.5m].
The Auxiliary Remote Station also requires a Seri
al I/O board (AUX 4249) to connect to
the MICRO 1000 Controller.
AccuBeam 3 Digital Line Guide Sensor
The Auxiliary Remote Station requires an interface cable and
T-box assembly (CON
1000) to connect to the Digital Line Guide.
Guide Point Adjust Remote Station or Web Width Monitor Remote Station
The Auxiliary Remote Station requires an interface cable and
T-box assembly (CON
1000) to connect to these remote stations.
Product Specifications:
Remote Station size (H x W x D): 2.52” [64mm] x 3.86” [98mm] x 1.41” [36mm]
Power requirements: Supplied by controller
Operating
environment:
Maximum ambient temperature 120 deg F [48.9 deg C]
Humidity 0-90%, Non-condensing
Installation
The Remote Station can be mounted in a variety of ways. The enclosure design allows the user
to easily remove the rear housing for panel-mount applications. Refer to the application drawings
and connection diagrams on page
137 for installation information.
Remote Station – Auxiliary
98
