Input A Type
1 2 0
Sensor A is not installed.
1 2 1
Sensor A is an ultrasonic or IR edge detector connected to the Edge
Detector A input. This is the default setting.
Note: Set parameter 55 to s
elect sensor type.
1 2 2
Sensor A is a digital line guide connected to the Serial I/O interface.
1 2 3
Sensor A is an external analog device connected to Analog Input 1.
Note: In order to select Input A through the front-panel switchpad, fieldbus or Discrete Isolated
Inputs, parameter 12 must be set to 1 or higher.
Input B Type
1 3 0
Sensor B is not installed. This is the default setting.
1 3 1
Sensor B is an ultrasonic or IR edge detector connected to the Edge
Detector B input.
Note: Set parameter 56 to s
elect sensor type.
1 3 2
Sensor B is a digital line guide connected to the Serial I/O interface.
1 3 3
Sensor B is an external analog device and is connected to Analog Input
2.
Note: If para
meter 2 is set to 1, then Analog Input 2 must be connected
to the actuator’s position-sensing potentiometer.
Note 1: In order to select Input B through the front-panel switchpad, fieldbus or Discrete Isolated
Inputs, parameter 13 must be set to 1 or higher.
Note 2: In order to select Centerline mode through the front
-panel switchpad, fieldbus or Discrete
Isolated Inputs, parameters 12 and 13 must both be set to 1 or higher.
Edge Detector A Signal Level
1 4 a a. b b b
This parameter displays edge detector A’s signal levels. Digits aa displa
the beam number and digits bbb display the signal level. Use the DATA
buttons to select the desired beam.
Edge Detector B Signal Level
1 5 a a. b b b
This parameter displays edge detector A’s signal levels. Digits aa displa
the beam number and digits bbb display the signal level. Use the DATA
buttons to select the desired beam.
MICRO 4000
NET Controller
20
