Edge Detector A Blocked Level
2 2 0
This parameter determines the blocked signal level for edge detector
A
and is automatically set by the edge detector calibration procedure. The
default value is 0.
Range: 0 to 255
This parameter value should not be changed manually.
Edge Detector B Blocked Level
2 3 0
This parameter determines the blocked signal level for edge detector B
and is automatically set by the edge detector calibration procedure. The
default value is 0.
Range: 0 to 255
This parameter value should not be changed manually.
Sensor A Length
2 4 2
This parameter configures the system for the number of sensing beams
in sensor A. The default value is 2.
Range: 2 to 128
Refer to the table of sensor models on page 57.
Note: To reduce the sensing area of a WideArray detector, change parameter 76.
Sensor B Length
2 5 2
This parameter configures the system for the number of sensing beams
in sensor B. The default value is 2.
Range: 2 to 128
Refer to the table of sensor models on page 57.
Note: To reduce the sensing area of a WideArray detector, change parameter 77.
Actuator Position Display
This parameter displays the position of the actuator. The display format depends on the type of
actuato
r installed:
2 6 0
Actuators with potentiometer feedback (MT, SF, HL, HF, HT, and UHT).
The data display indicates the position of the actuator’s end-of-travel
potentiometer.
Range: 0 to 255
2 6 a b c
Actuators with limit switches (MM, MME, MN, and MNE). The data
display indicates the state of the actuator’s limit switches:
a =
IN limit switch (0 = activated, 1 = deactivated)
b = POLARITY switch (0 = activated, 1 = deactivated)
c = OUT limit swit
ch (0 = activated, 1 = deactivated)
2 6 a b c
Actuators with limit switches (MX). The data display indicates the state o
f
the actuator’s limit switches:
a = don’t care
b = don’t care
c = OUT POL
ARITY switch (0 = activated, 1 = deactivated)
MICRO 4000
NET Controller
22
